1653nm Filter for Methane CH Gas Detection Applications
1653nm filter for methane CH gas detection is a near-infrared band pass filter, widely used in gas detection filters, unmanned radar, near-infrared detection and other high-tech fields.
| Item | Parameters |
| Product name | 1653nm Filter for Methane CH Gas Detection Applications |
| Model number | BP1653 |
| CWL | 1653±2nm |
| AOI | 0° |
| FWHM | 25±3nm |
| Transmittance | T＞90% Customized |
| Blocking Rate | >OD3-OD6 UV-NIR |
| Blocking Band | 200nm-2000nm Customized |
| Raw material | BK7 D263T JGS1 or other optical glass |
| Surface quality（S/D） | 60/40 or better |
| Dimension | 3mm-80mm Customized |
| Thickness | Customized |
Yangzhou UTE Optical Technology Co., We are specialized in manufacturing and supplying optical elements. Optical filter,narrow band optical filter,Long Pass Filter,Short Pass Filter,Band Pass Filter,UV IR Cut Off.etc
