BP560nm Band Pass Filter
| Item | Parameters |
| Product name | BP560nm Band Pass Filter |
| Model number | BP560nm |
| Description | High Reflection Filters |
| Process | IAD Hard Coating |
| CWL | 560±5nm |
| FWHM | 20nm |
| Transmittance | T＞85% |
| Cut off rate: | OD4 200-1100nm |
| Raw material | BK7 or Corning gorilla glass or other optical glass |
| Surface quality（S/D） | 60/40 or better |
| Dimension/Round Size | D12x6mm D15x5mm |
| Dimension/Square size | 80x80x1mm |
Yangzhou UTE Optical Technology Co., We are specialized in manufacturing and supplying optical elements. Optical filter,narrow band optical filter,Long Pass Filter,Short Pass Filter,Band Pass Filter,UV IR Cut Off.etc
